Cu/Mo/Cu CMC111 Heat Spreader Golden Color For RF And Microwave Amplifiers

China Cu/Mo/Cu CMC111 Heat Spreader Golden Color For RF And Microwave Amplifiers supplier

Large Image :  Cu/Mo/Cu CMC111 Heat Spreader Golden Color For RF And Microwave Amplifiers

Product Details:

Place of Origin: CHINA
Brand Name: JBNR
Model Number: CMC111,CMC121,CMC131,CMC141,CMC13/74/13

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: as customer required
Delivery Time: 15days
Payment Terms: L/C, , T/T, Western Union
Contact Now
Detailed Product Description
Material: Copper/moly/copper Density: 9.32
CTE: 8.8 TC: 250
Application: RF And Microwave Industry

Cu/Mo/Cu CMC111 heat spreader for RF and Microwave Amplifiers


Description:



CMC or CPC is a sandwich composite, CMC including a molybdenum core layer and two copper clad layers, CPC including a Mo-Cu alloy core layer and two copper clad layers . They have different CTE in X and γ direction, with higher thermal conductivity than that of W (Mo)-Cu.


Advantages:

1.Can be stamped into components
2.Strong interface bonding resist to 850℃ heat shock repeatedly
3.High thermal conductivity
4.Semi-finished or finished (Ni/Au plated) products available

Product Properties:



Grade Density g/cm3

Coefficient of thermal

Expansion ×10-6 (20℃)

Thermal conductivity W/(M·K)
CMC111 9.32 8.8 305(XY)/250(Z)
CMC121 9.54 7.8 260(XY)/210(Z)
CMC131 9.66 6.8 244(XY)/190(Z)
CMC141 9.75 6.0 220(XY)/180(Z)
CMC13/74/13 9.88 5.6 200(XY)/170(Z)





Application:


Cu/Mo/Cu(CMC) heat sink has similar applications with tungsten copper heat sinks. It can be used as thermal mounting plates, chip carriers for microwave, flanges and frames for RF, laser diode packages, LED packages, BGA packages and GaAs device mounts etc.



Product picture:

Cu/Mo/Cu CMC111 Heat Spreader Golden Color For RF And Microwave Amplifiers
